Trimble TMX-2050 - AG-815 integrated radio

Connections
Power
(14-pin Ampseal connector)
Power input
CAN
2x Digital In / Out
12 volt power output (non-regulated, fused)
Ignition Sense
I / O
(12-pin DEUTSCHconnector)
CAN
RS232
Digital In
Digital Out
Video In (640 x 480 resolution) NTSC&PAL
12 volt power output
Display Ethernet
(White 8-pin Ampseal
connector)
Display power
28 volt, 2 amp output
Display Ethernet Communications
Video Out
Ignition Sense
Secondary Ethernet
(Black 8-pin Ampseal
connector)
Ethernet Communications
12 volt power output
Video In
GPS / GNSS
(TNC connector)
GPS / GNSSantenna
5 volt
AG-815 integrated radio
Technical
Power Via TM-200 module
Mechanical
Dimensions 144 mm x 81 mm x 52.5 mm (plus connectors) (5 43/64 in x 3 3/16 in x
2 1/16in)
Version 1.075, Revision C TMX-2050 Display User Guide 15
