Mechanical
Weight 0.55 kg (1.22 lb)
Mount The AG-815 module attaches directly to the TM-200 module with
four M3 x 16 mm (5/8 in) screws
Housing
Material Aluminum
Environmental rating IP55
Temperature
Operation -40 °C to 65 °C (-40 °F to 149 °F)
Storage -40 °C to 85 °C (-40 °F to 185 °F)
GNSS
Internal 220 channel GNSS receiver, L1/L2/GLONASS capable
Radio options 450 MHz radio 900 MHz radio
Range 13 km (8 miles); varies with terrain
and operating conditions
13 km (8 miles); varies with terrain
and operating conditions
Frequency range
430 to 450 MHz, 450 to 470 MHz
(region-dependent)
902 to 928 MHz
Networks 20 user-selectable networks 40 user-selectable networks
Wireless data rates
128 Kbps
128 Kbps
Modes Rover (receive only) Rover (receive only)
Connections
Radio (TNC connector)
Radio antenna
16 TMX-2050 Display User Guide Version 1.075, Revision C
