Trimble TMX-2050 - Equipment setup

ISOBUS for implements 8 Implements
Tap... To...
Coverage Switching
Overlap
Enter the percentage of a section's width that must be in a
previously covered area before the system switches the section
off. The higher the number, the greater the overlapped area
before the section is turned off.
Boundary Switching
Overlap
Enter the percentage of a section's width that must be past a
boundary before the system switches the section off. The higher
the number, the greater the overlapped area before the section is
turned off.
14.
At the SUMMARY screen, review the settings and tap to save the settings for this channel.
15. For each additional channel, complete steps 9 through 14.
16.
Complete the implement setupand save the Implement Summary. For instructions on Boom
Height, Inputs and Summary, see:
ll Boom height control, 210
l Inputs, 219
l Review implement summary, 222
17. If you have not already done so, complete the setup for sending GNSSsignals to the implement
(see CAN message settings, 130).
18. Set up the ISO-certified equipment to use Task Controller. See Equipment setup, 195.
To operate the Task Controller, see Task Controller operation, 282.
Equipment setup
As part of getting the implement ready to be controlled by Task Controller, you use Virtual Terminal
to set the configuration for the implement.
1. Make sure the ISO-certified implement is connected and Virtual Terminal is turned on in
Settings (see ISOBUS settings, 87).
2.
At any screen access the main menu by tapping . The main menu displays.
3.
Tap . The Virtual Terminal displays.
4. Follow the instructions for the equipment you are using to set the implement for using Task
Controller. See the ISOBUSGetting Started Guide for the TMX-2050 Display.
Version 1.075, Revision C TMX-2050 Display User Guide 195
