Boom height control 8 Implements
For information on: See:
Adjustment
during operation
Boom height adjustments, 278
Calibrate boom height control
Each boom's hydraulic drive must be calibrated before you can use the Field-IQ system Boom
Height Control on the Run screen. Before you calibrate boom height control:
l Complete the implement and boom height configuration.
l Take the equipment to a field with a firm, natural surface (not concrete, not freshly tilled).
l
Make sure that the hydraulic fluid is at normal operating temperature.
Note – On some vehicles with large reservoirs, it may take a longer amount of time for the
fluid to reach operating level, especially if the implement circuit is lightly loaded. Consult the
vehicle documentation to determine if the hydraulic fluid temperature can be shown on a
vehicle console.
l Use the manual control panel to test the system prior to calibration. See Boom height manual
control test, 216.
For information on: See:
Diagnostics
Boom Height Diagnostics, 300
Control during operation
Boom height control operation, 276
Adjustment during
operation
Boom height adjustments, 278
Boom height calibration steps
1. Access the calibration for boom height control.
a.
At the Home screen, tap .
b. Tap the implement you want to calibrate, and then tap Select.
c. Tap Calibration.
d. Tap Boom Height. The boom height calibration panel displays.
e. Tap Calibrate for the boom you want to calibrate.
2.
Tap BOOM CALIBRATION.
Version 1.075, Revision C TMX-2050 Display User Guide 215
