Trimble TMX-2050 - Boundary editing (Field Manager)

Guidance patterns 10 Operations
3. Tap .
4.
When you are ready to begin your boundary tap and begin driving the perimeter of the
field or area. The display:
ll Marks the point where you began recording
l Shows the recorded path with a dashed line
5. Drive around the field until you are near your starting point.
ll If Auto-Close is on: When you reach auto-close distance , the display will connect the
vehicle's current location to the starting point with a straight line and save the boundary.
l
If Auto-Close is off: Drive to the beginning point and tap The display will connect the
vehicle's current location to the starting point with a straight line and save the boundary.
To set the auto close feature, see Patterns settings, 83.
6. When finished, the display makes the boundary you created active, and saves it with a unique
name. The distance between swath lines is based on the width of the implement that was used
to create the line.
7.
To suspend recording while creating the boundary, tap .The display will replace the path
you travel while paused with a straight line, from the point where you tapped to the
point where you resume recording. To resume recording, tap or .
8.
To cancel the boundaryline creation, tap .
9. To edit any boundary you have created, see Boundary editing (Field Manager), 249.
Boundary editing (Field Manager)
1.
At the Home screen, select the field where you want to edit the boundary. Tap to open
the Field Manager.
Or if you are at the Run screen, tap to open the Field Manager for the field you are
currently in.
2.
At the Field Manager, tap BOUNDARIES.
The map and the Boundaries list show the boundaries in the selected field(s).
Version 1.075, Revision C TMX-2050 Display User Guide 249
