Guidance patterns 10 Operations
8.
To cancel the pivot creation, tap .
Guidance pattern editing (Field Manager)
1.
At the Home screen, select the field where you want to edit the boundary. Tap to open
the Field Manager.
Or if you are at the Run screen, tap to open the Field Manager for the field you are
currently in.
2.
Tap GUIDANCEPATTERNS. The map and the Patterns list show the patterns in the selected
field.
3.
Tap the pattern you want to edit.
The pattern must be active before you can edit it. If the pattern is not active, tap (red) to
make it active.
4.
The display highlights the active pattern in blue on the map.
5. If you have chosen a headland, you can change the number of circuits in a headland.
6.
Tap to resize the pattern you have chosen.
Or for a pivot pattern, tap .
7.
Edit the size of the pattern and tap .
8.
To cancel the change, tap .
9.
To exit Field Manager, tap .
For information on: See:
Field Manager
Field Manager, 61
Pattern activation/deactivation (Field Manager)
You can activate or deactivate patterns in a selected field. To engage your auto guidance system on
a line, pattern or headland, it must be active.
Version 1.075, Revision C TMX-2050 Display User Guide 259
