Trimble TMX-2050 - ISOBUS diagnostics; Device tab; Recording and saving CAN logs

ISOBUS diagnostics 11 Diagnostics / troubleshooting
ISOBUS diagnostics
At the Diagnostics panel, tap Task Controller/Virtual Terminal under ISOBUS.
Device tab
Display Information Explanation
Device Name Name of device
Device S/N Device's serial number
Software Version Version of ISOfirmware
CANConnection Status of CANconnection
Pool Loaded Yes or No. Indicates data from ECUis loaded.
ISO-TC Task Controller data is available.
ISO-VT Virtual Terminal data is available.
Note – If ECUdata does not auto-populate, it may be necessary to cycle power to the ECU.
Note – If the implement's ECU is power cycled while still in the Run screen, it is necessary to exit and
re-enter the Run screen before being able to resume Task Controller.
Recording and saving CANlogs
1. At the Diagnostics panel under System, tap Logging/CANLogs.
2.
For the appropriate port, tap to begin the recording.
3.
Tap again to stop recording.
4. Insert a USB drive into a USBsocket of the TMX-2050 display.
5.
Tap to transfer the logs to the USBdrive.
Version 1.075, Revision C TMX-2050 Display User Guide 323
