5 Connectivity DCM-300 modem initial setup
CAN message settings
If you wish to send messages from the GNSSreceiver in the TM-200 Module, you can set up what
messages will be sent from CANport A or B. If you are using an ISO-certified implement, use this
setting to sent information to the implement such as speed. (See ISOBUS for implements, 191.)
1.
Tap the CANport that you want to change settings for. Choose the messages for the
GNSSreceiver in the TM-200 Module to send to ISO-certified equipment.
The list that displays for each CANport shows the messages and their parameter group number
(PGN). For each message, you can choose how often the message is sent:
ll Off (never sent)
l 10 Hz, 5 Hz or 1 Hz
l Every 5, 10, 30 or 60 seconds
2.
Tap to save your settings.
DCM-300 modem initial setup
The DCM-300 modem ships as a locked unit until it is installed with the display. See Connect the
DCM-300 modem, 111.
To use VRS correction or data transfer features, activate and configure these services.
1. Connect the DCM-300 modem to the display.
2. Power on the DCM-300 modem and display.
3. Activate the required services on the display. See Feature unlocks, 81.
a. To use VRS corrections, activate RTK and VRS.
b. Vehicle Sync and Office Sync also require activation.
4. Reboot the DCM-300 modem by turning off the vehicle ignition.
5.
On the Home screen, tap , then tap Settings. The system settings panel displays.
6. Tap Modem Service.
7. Continue the instructions for setup at Modem services settings, 88.
Office Sync setup
With the Office Sync service, you can electronically transfer data from the display to the office and to
Connected Farm dashboard. Data will be:
130 TMX-2050 Display User Guide Version 1.075, Revision C
