Trimble TMX-2050 - Guidance patterns; Guidance creation buttons

10 Operations Guidance patterns
Guidance patterns
Guidance items you can place in the field from the Run screen include:
l Boundaries
l Straight or curved lines
l Headlands
l Pivots
After you have created guidance items, you use Field Manager to:
l Edit guidance lines, patterns and boundaries.
l Activate or deactivate boundaries, guidance lines and patterns.
To create: To edit: Settings/adjustments:
Go to the Run screen. See:
l AB guidance line creation
(Run screen), 251, A+
guidance line creation (Run
screen), 252, Curved line
creation (Run screen), 252
l Boundary creation (Run
screen), 248
l Headland and infill pattern
creation (Run screen), 253,
Pivot pattern creation (Run
screen), 258
Open Field Manager. See:
l Guidance pattern
editing (Field Manager),
259
l Boundary editing (Field
Manager), 249
At the Run screen:
Adjust during field activities:
Guidance pattern adjustment
(Run screen), 260
At Settings:
Set where the beginning of the
guidance line begins in relation
to the equipment. See Patterns
settings, 83
At the Run screen, tap to access the buttons for creating boundaries, guidance lines and
headlands and pivots.
Guidance creation buttons
Button Tap to...
Boundary
Record the perimeter of a field. You can use boundaries to:
l Calculate area
l Switch implement sections on and off at the edge of the field
l Generate end of row warnings
See Boundary creation (Run screen), 248.
246 TMX-2050 Display User Guide Version 1.075, Revision C
