Autopilot system setup 6 Vehicles
Tap... Explanation
Vehicle ProfileOrigin
The source of the vehicle profile:
ll Vehicle Profiles Database: contained in the display
l Import from Navigation controller: If your navigation
controller has already been set up for a different
Trimble display, the vehicle profile is stored in the
controller.
l Import from USB: profile stored on USB drive (These
configuration /.cfg files are located in the
AgData/Profiles folder on the USB drive.) (See USB
transfer of vehicle configuration for Autopilot in Data
transfer, 67.)
CAUTION – If you select a Vehicle Profile that is not
suitable for your vehicle, you may experience degraded
system performance.
GNSSSetupSelection
If you have not completed GNSS setup. See
GNSS receiver
settings, 116
.
Configure GNSS
Setup GNSS if you have not already done so.
WARNING – Many large and sudden changes in satellite geometry caused by blocked satellites can cause
significant position shifts. If operating under these conditions, auto-guidance systems can react abruptly. To
avoid possible personal injury or damage to property under these conditions, disable the auto-guidance
system and take manual control of the vehicle until conditions have cleared.
3. Tap Next to continue to Controller settings for Autopilot system, 147.
Controller settings for Autopilot system
The navigation controller indicates to the TMX-2050 display how your vehicle is positioned. To set
up the controller, you must indicate the position/orientation of the controller as it is currently
installed in the vehicle.
For example, if the controller is positioned with the input jacks of the controller facing to the left side
of your vehicle, you indicate this in the TMX-2050 display.
The CONTROLLERSETTINGS section of the vehicle setup panel shows an image of the controller as
though you are looking down on the vehicle from above, with the front of the vehicle at the top of
the screen.
Version 1.075, Revision C TMX-2050 Display User Guide 147
