Autopilot system calibration 6 Vehicles
3) Reposition the vehicle so that the turn will use the space that you have available.
4) Tap the button to begin the next phase.
2.
At the Vehicle setup panel, select the vehicle profile you want to work with. See Select a vehicle,
145 for detailed instructions.
3. On the left-hand side, tap Calibrate.
4. Tap Automated Steering Dead Zone. The calibration panel displays.
5. Center The steering and tap Next.
6. Read each instruction and then tap Next.
7.
Center the steering on the tractor and move forward in first gear at high RPM for at least five
seconds.
8. Tap Test Right and continue moving forward while the system performs a coarse right side test.
9. When the test is finished, center the steering again and drive forward for five seconds.
10. Tap Test Left and continue moving forward while the system performs a coarse left side test.
11. Tap Accept to accept the calibration. The system displays the AutoPilot calibration panel again.
12.
Continue driving ahead slowly and tap Test Right. The system will perform the first right hand
fine calibration.
13.
Repeat the right and left hand fine calibrations until there is a change of less than .5 in each of
the deadzone values
To minimize the total amount of space needed for the complete calibration, you can reposition
the vehicle between each calibration process.If available flate, smooth space is extremely
limited, re-align the vehicle after each calibration.
Note – If you encounter any error messages during calibration, refer to the Automated
Deadzone error messages in this section.
Automated Deadzone error messages
Message:Error - .... Explanation
Manual Override Detected Manual override was detected before the calibration cycle could be
completed. Retry the calibration.
No GPS A GNSS receiver must be connected and outputting positions before
the software can run the calibration procedure.
No Steering Response
Detected
During the calibration cycle, there was not enough movement for
the calibration to complete. If the problem persists, the hydraulic
installation could be faulty.
