8 Implements Application control
Application control
Note – For the correct connection of equipment, refer to the Connecting the Field-IQ system's Crop
Input Control Systems chapter in the TMX-2050 Display Cabling Guide.
Application Control includes settings for rate and section control. When the Field-IQ feature is
installed, the TMX-2050 display can control spraying.
Prior to setup
Before you can set up Field-IQ Rate and/or Section Control, you must complete the following:
l Install Field-IQRate and/or Section Control.
l Add, configure and calibrate a vehicle. See Add a vehicle, 140.
l
Set up an implement. See Implement setup, 188.
Channel setup
To set up application control for the Field-IQ system, complete the following steps:
1. Turn on application control and Add a control channel, 197.
2. For each control channel, complete the following settings as they apply to your equipment:
ll Section control, 198
l Rate control, 202
l Adjustments, 207
3. Review the channel configuration, see Summary, 207.
4. To calibrate drives for Rate and Section Control, see Calibrate application control drives, 205.
Setup diagram
The following diagram shows the setup sequence for a sprayer with Rate and Section Control.
196 TMX-2050 Display User Guide Version 1.075, Revision C
