10 Operations Guidance patterns
The display highlights the active pattern in blue on the map.
For headland boundaries (inner and outer), the list shows the implement type and width used
to create each pattern.
3. To select a boundary, tap it on the map or in the list on the left-hand side of the screen.
4.
To edit the pattern, use the buttons on the right-hand side of the screen.
Note – The display shows only the options that are suitable for the selected item.
Tap... To...
Name
Use the on-screen keyboard to rename the selected item.
Resize
Note – Not
available on
headland
boundaries.
To resize the boundary:
a.
Tap .
b. Tap the text box and use the on-screen number pad to enter the
distance to move the boundary.
c. To shift the boundary outward (making the area larger), tap Expand.
d. To shift the boundary inward (making the area smaller), tap Contract
to shift the boundary inward (making the area smaller).
e.
Tap . The display saves a copy of the pattern with a new name at
the new position.
Delete
Remove the selected pattern.
5.
To save the changes and close the Field Manager, tap .
For information on: See:
Field Manager
Field Manager, 61
Boundary activation/deactivation (Field Manager)
You can activate or deactivate boundaries in a selected field.
