EZ-Steer system setup 6 Vehicles
EZ-Steer system setup
The EZ-Steer system turns the steering wheel for you by combining a friction wheel and a motor
with guidance from the TMX-2050 display.
Initial setup steps are:
l Guidance selection for EZ-Steer system, 173
l Controller settings for EZ-Steer system, 173
l Steering and speed settings for EZ-Steer system, 173
l Vehicle measurements for EZ-Steer system, 175
Guidance selection for EZ-Steer system
WARNING – Auto guidance systems cannot avoid items in the field such as obstacles. Make sure you are
adequately trained to operate the auto guidance system.
1. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
edit. The display changes the list item to a blue background with white text.
c. Tap Edit, then GUIDANCE.
2.
At the SELECTIONS section,tap Selection and then tap EZ-Steering.
WARNING – Many large and sudden changes in satellite geometry caused by blocked satellites can cause
significant position shifts. If operating under these conditions, auto-guidance systems can react abruptly. To
avoid possible personal injury or damage to property under these conditions, disable the auto-guidance
system and take manual control of the vehicle until conditions have cleared.
3. Tap Next to set up the controller orientation. See Controller settings for EZ-Steer system, 173.
Controller settings for EZ-Steer system
Setting Explanation
Connector Faces Indicate how the connector on the navigation controller faces:Back, Floor,
Front
Steering and speed settings for EZ-Steer system
Note – Adjust settings only if necessary to improve steering performance.
Version 1.075, Revision C TMX-2050 Display User Guide 173
