6 Vehicles EZ-Steer system setup
1. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
edit. The display changes the list item to a blue background with white text
c. Tap Edit, then GUIDANCE.
2.
Tap SETTINGS. Complete the information at the SETTINGS section.
Steering Sensor
Setting
Description
Angle per Turn The angle that the wheels turn during one full rotation of the steering
wheel (1 - 150 degrees):
ll Too high - the system turns the wheel too little and the vehicle will not
hold the line
l
Too low - results in small, fast oscillations in steering
Angle per turn values should be calibrated first using EZ-Steer calibration
and then adjusted here if necessary.
Freeplay Left The amount of free movement in the steering when starting a left turn (0 -
11.9 inches (0 - 30 cm))
Freeplay Right The amount of free movement in the steering when starting a right turn (0
- 11.9 inches (0 - 30 cm))
Steering Delay
Note – Only
available if
vehicle is
sprayer or
swather.
The amount of time between steering wheel movement and vehicle yaw
rate change (0.1-1.5 seconds)
Note – This value should only be used for swathers and sprayers.
Motor Speed The speed at which the motor will operate:
ll Auto, Auto Low, Auto Medium, Auto High, or Auto Maximum
l Manual Low, Manual Medium (Default), Manual High, or Manual
Maximum
Note – Auto mode determines the proper speed for the steering action
required.
