10 Operations Guidance patterns
implement that was used to create the line.
7.
To cancel the ABline creation, tap .
A+ guidance line creation (Run screen)
With A+ lines, you define a point on the line and the direction the line is heading.
1.
Select a vehicle, implement and field. (See Select a field, 182.)
Note – The display uses the implement width to project swaths for the master line.
2. Enter the field where you want to create the line. (See Preparing for operation, 234.)
3.
Tap . The pattern buttons display.
4.
Tap . The display changes to overhead view if you were in trailing view. The A point is set at
the vehicle's current location. The A+ line controls appear in the center of the screen.
5. Select the direction you want for the A+line.
6. To set the direction of the line, you can do any of the following:
ll
To use the direction that the vehicle is facing as the heading, tap .
l To use the on-screen number pad to enter an exact heading, tap the number.
l To use a cardinal (N, S, E, W) or ordinal (NE, SE, SW, NW) direction, tap that direction on
the compass ( ).
The display saves the line. The distance between swath lines is based on the width of the
implement that was used to create the line.
7.
To accept the line and direction and close the controls, tap . The display saves the line.
The distance between swath lines is based on the width of the implement that was used to
create the line.
8.
To cancel the line creation, tap .
Curved line creation (Run screen)
1. Enter the field where you want to create the boundary. (See Preparing for operation, 234.)
2.
Tap . The pattern buttons display.
3.
Tap .
252 TMX-2050 Display User Guide Version 1.075, Revision C
