2 Display basics Field Manager
Button or Entry Box Tap to...
Activate Shape
(Red)
Activate a pattern (headland, boundary, pivot).
SeePattern activation/deactivation (Field Manager), 259.
Adjust the radius of a pivot shape.
For more information, see Guidance pattern editing (Field Manager), 259.
Resize a shape other than a pivot shape.
See Guidance pattern editing (Field Manager), 259.
Shift a line.
See Guidance pattern editing (Field Manager), 259.
Delete a selected boundary.
Boundary Name Change the name of the highlighted boundary.
Landmark buttons
Button or Entry Box Tap to...
Category
Assign a category to a landmark point, line or area.
For more information, see Pattern activation/deactivation (Field Manager),
259.
Convert
Convert a selected:
l Productive area to a non-productive one
l Non-productive area to a productive one
See Pattern activation/deactivation (Field Manager), 259.
64 TMX-2050 Display User Guide Version 1.075, Revision C
