Trimble TMX-2050 - Valve;Drive

Application control 8 Implements
Tap... To...
Valve/Drive Behavior
when Sections
Closed
Set the behavior when sections are closed.
ll Close - When all sections are off, the control valve returns to the
closed position.
l Lock in Minimum Position - When all sections are off, the control
valve remains at the minimum flow position. This option applies
to PWMdrives only.
l Lock in Last Position - When all sections are off, the control valve
remains in the last position. This setting allows the system to
return to the target rate faster. This option applies to Servo
drives only.
3. Tap Next to continue to Valve/Drive, 203.
Valve/Drive
1.
At the VALVE/DRIVE section for Rate Control, tap the box that represents each drive and set the
required values.
Tap... To...
Serial Number
Choose the serial number of the Rate Control Module at this location.
The display shows the serial numbers from the installed modules.
Flow Meter Type
Select the type of flow meter installed for this drive. (Raven, Trimble,
or Other).
Flow Meter
Calibration Number
Enter the calibration number from the tag on the flow meter. The
display calculates the calibration pulses per unit of volume.
ll Raven - pulses per 10 gallons (liters)
l Trimble - pulses per gallon (liter)
l Other - pulses per gallon (liter)
Units (only if Flow
Meter Type is Other)
Choose the unit of measurement used by the flow meter.
ll Pulses per gallon (liter)
l Pulses per cubic inch (centimeter)
2.
Tap . Then tap Next to continue to Width, 204.
Version 1.075, Revision C TMX-2050 Display User Guide 203
