Trimble TMX-2050 - AG-815 integrated radio

Components 4 Installation
For information on: See:
Connecting the
modem
Connect the DCM-300 modem, 111
Modem status
DCM-300 modem status, 302
AG-815 integrated radio
The AG-815 integrated radio provides access to radio networks for real-time, high-precision
CenterPoint™ RTK applications. The AG-815 is available in both the 450 MHz and 900 MHz versions.
Item Name Explanation
1 Radio blade connector Connection to TM-200 Module. See
TM-200 Module, 97
,
number 8.
2 Antenna connector
Radio antenna connector
3 Antenna connector Optional GNSSconnector for future use
Version 1.075, Revision C TMX-2050 Display User Guide 99
