11 Diagnostics / troubleshooting Field-IQ diagnostics
Rate Control
Item Explanation
Minimum
Override Speed
Change this setting. When the vehicle drops below this speed, the system
maintains the application rate for this speed. This ensures consistent material
flow at low speeds.
System Minimum
Flow
Enter the minimum flow rate required by the drive, control valve or flow
meter. This setting keeps the flow above the minimum operating level
required by the equipment.
Manual Rate
Switch
Aggressiveness
Increase or decrease aggressiveness of the manual rate switch.
When the Rate switch is in the Manual position, this controls how quickly the
valve opens/closes when you use the rate increment/decrement switch on
the master switch box.
Note – This setting does not affect automatic rate control.
Overlaps
Item Explanation
Start Overlap The amount of overlap (distance) you want when starting coverage.
When you are in a previously covered area driving toward a non-covered
area, the system will begin turning sections on at this distance before
reaching the non-covered area.
Stop Overlap The amount of overlap (distance) you want when stopping coverage.
When you are applying material and driving toward a previously covered
area, the system will keep sections on until they are this far into the
previously covered area.
Coverage
Switching Overlap
The percentage of a section's width that must be in a previously covered area
before the system switches the section off. The higher the number, the
greater the overlapped area before the section is turned off.
Boundary
Switching Overlap
The percentage of a section's width that must be past a boundary before the
system switches the section off. The higher the number, the greater the
overlapped area before the section is turned off.
312 TMX-2050 Display User Guide Version 1.075, Revision C
