Trimble TMX-2050 - Landmark point creation (Run screen); Landmark line creation (Run screen)

10 Operations Landmarks
Landmark point creation (Run screen)
1. Select a vehicle, implement and field. (See Select a field, 182.)
2.
Tap to enter the field.
3.
Tap .
4.
Tap . The display places a marker at the vehicle's current location, based on the recording
point.
5. To edit or rename landmarks you have already created, go to Field Manager. For instructions,
see Field Manager, 61.
6. To record a different type of landmark by default, or to change the point on the
vehicle/implement used to indicate the location of the landmark, tap Change landmark
settings. For instructions, see
7.
Toclose the landmark buttons, tap .
Landmark line creation (Run screen)
1. Select a vehicle, implement and field. (See Select a field, 182.)
2.
Tap to enter the field.
3.
Tap .
4.
Tap the line button .
5.
Tap . The display draws a dashed line beginning at the vehicle's current location, based
on the recording point.
6.
Drive to the end of the line you want to record and then tap again.
7.
To discard a path that is being recorded but has not been saved, tap . The path recorded so
far is not saved.
8. To start over, tap the button for the feature again.
9. To edit or rename landmarks you have already created, go to the Field Manager. For more
information, see Field Manager, 61.
264 TMX-2050 Display User Guide Version 1.075, Revision C
