Autopilot system setup 6 Vehicles
Tap... To...
Steering Sensor Select the type of angle sensor installed on the vehicle:
ll Potentiometer
l AutoSense™ device
AutoSense
Location
Select the location of the AutoSense device:
ll Left Wheel
l Right Wheel
AutoSense
Orientation
Indicate the direction the AutoSense label is facing:
ll Label Up
l Label Down
Note – If the orientation is not accurate, assisted steering may be
affected.
Valve On Speed Select speed. For vehicles operating at very slow speeds, select Low or
Ultra Low.
ll Normal - 1.3 ft/s (0.4 m/s)
l Low - 0.3 ft/s (0.1 m/s)
l Ultra Low - 0.07 ft/s (0.02 m/s)
Vehicle measurements for Autopilot system
Note – For Autopilot guidance with untracked or tracked vehicles, do not change vehicle
measurements unless they are not correct.
At MEASUREMENTS, you can enter and access the measurements that apply to the vehicle type you
selected. In addition to measurements of the vehicle itself, measurements related to the antenna
location are important for accuracy.
1. Before you take measurements:
a. Park the vehicle on level ground.
b. Make sure the vehicle is straight, with the center line of the body parallel to the wheels.
2. Navigate to the MEASUREMENTS section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. Tap Edit.
c. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
edit. The display changes the list item to a blue background with white text.
d. Tap Edit, then GUIDANCE.
3.
Tap MEASUREMENTS. Based on your selections up to this point, some measurements will be
Version 1.075, Revision C TMX-2050 Display User Guide 149
