Application control 8 Implements
Tap... To...
Rate Snapping Turn setting on or off. This setting smooths out rate fluctuations seen on
the screen.
l Off: The display shows instant readings from the feedback sensor.
This may show frequent minor rate fluctuations.
l On: The display smoothes out the values. You will see the target rate
as the applied rate whenever the applied rate is within 10% of the
target rate.
Calibrate application control drives
WARNING – When the implement is down and the master switch is in the On position, the machine is fully
operational. Take all necessary precautions to ensure user safety. Failure to do so could result in injury or death.
1.
At the Home screen, tap . The Implement setup panel displays.
2. At the list on the left-hand side, tap the implement you want to calibrate, then tap Select.
3. Tap Calibrate. The calibration section opens at the Summary section.
4. Tap Application Control.
5. Tap the channel to calibrate it. A popup displays.
6.
TapCalibrate. The calibration tool displays, beginning atthe Drive Limits section.
ll If Maximum Flow is unknown, use the default (0.00) to allow the system to determine
maximum flow.
l You can also use this formula to calculate Maximum Flow:
boom width x ground speed x application rate x calculation factor
l For metric systems, use meters for width and kph for ground speed, with a calculation
factor of 0.00167.
l For standard systems, use feet for width and mph for ground speed, with a calculation
factor of 0.00202.
7.
Tap Next to continue to the Drive Settings section.
Setting Description
Target Speed Enter the test speed to use during calibration. The system will
apply material at the rate required to reach the Target Rate if the
vehicle travels at this speed.
Version 1.075, Revision C TMX-2050 Display User Guide 205
