Inputs / Sensors calibration
1.
At the Home screen, tap . The Implements panel displays.
2. Select the implement and then tap Select.
3. Tap Calibrate.
4. Tap INPUTS.
5. Tap the sensor you want to calibrate. A popup displays.
6. Tap Calibrate.
7. Tap Enabled.
8. Tap Calibration Type and select the type of calibration you wish to perform:
a. High/Low - More accurate and requires a pressure gauge for reading the actual pressure.
(If you chose this type, continue to step 9.)
b. Point/Slope - Requires a slope value for the equipment from the manufacturer of the
implement. (If you chose this type, continue to step 10.)
9. To complete calibration for the High/Low method:
a. Tap Start Calibration.
b. Read the instructions on the screen and then tap Next to begin.
c. Without the system running, take a reading. Enter this value into the Actual Pressure field
and then tap Next.
d. Run the system at normal working pressure and take a reading. Enter this value into the
Actual Pressure field.
e. Tap Next.
f. Run the system at normal working pressure and take a reading. Enter this value into the
Actual Pressure field.
g. Run the system from low to high levels to verify the change in sensor readings.
h. Tap Accept or tap Recalibrate to repeat the process
10. To complete calibration for the Point/Slope Method:
a. Enter the Slope value for the sensor from the manufacturer.
b. Tap Start Calibration.
c. For Actual Pressure, enter the current pressure. Tap Next to continue.
d. Review the results. If the Measured Pressure is not accurate, tap Recalibrate and repeat
the calibration with a new Slope value.
e. Tap Accept when the Measured Pressure is accurate.
