For the Antenna Height, measure the distance from the ground to the base of the GPS receiver (or
antenna).
EZ-Steer system calibrations
Calibrations for the EZ-Steer auto guidance system include:
l Angle per turn calibration for EZ-Steer system, 176
l Roll correction for EZ-Steer system, 176
For information on: See:
Diagnostics
EZ-Steer system diagnostics, 307
Roll correction for EZ-Steer system
1. Park the vehicle and mark the center lines of both the front and rear wheelbases on the
ground.
2. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
calibrate. The display changes the list item to a blue background with white text.
3. Tap Calibrate.
4. Tap Roll Calibration. The calibration tool displays.
5. Follow the instructions on the calibration tool.
6.
To accept the calibration, tap .
7.
To discard the calibration and start it again, tap .
Angle per turn calibration for EZ-Steer system
Perform the Roll calibration before performing the angle per turn calibration.
1. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
calibrate. The display changes the list item to a blue background with white text.
2. Tap Calibrate.
176 TMX-2050 Display User Guide Version 1.075, Revision C
