10 îîOperations On-screen widgets
On-screen widgets
Widgets are software gadgets on the screen that can provide functionality control, information and
status on the Run screen during field activities.
There are two types of widgets:
l Status widgets:îProvide information only and do not control any function
l Control widgets: Enable you to control a function, and may include status information
For some widgets, you can choose to display or not display them.
Other widgets display when you are performing a specific task, such as operating with the Task
Controller (see Task Controller operation, 282.)
Access widgets
To access the list of widgets available on your TMX-2050 display:
1.
At the Run screen, tap .
2. To display all widgets, tap Add All Widgets.
3. To remove all widgets, tap Remove All Widgets.
Minimize/maximize, resize
Some widgets can be maximized from their normal minimized size. To maximize a widget, tap the
upper right corner of the widget. To make it smaller, tap the same upper right corner.
Other widgets can be re-sized to a customized size. To make a widget larger, touch the upper right
corner of the widget and hold. Arrows display on all sides of the widget. Touch and drag one of the
arrows to resize. When you are satisfied with the size, remove your finger. The following widgets can
be re-sized:
l Position status, 289: On-screen lightbar, compass, digital compass and swath number
l Speed status, 290
l Virtual Terminal widget, 290
Move a widget
You can position some widgets on the screen where it makes sense for you. The position on the
screen where you have chosen to display each widget is saved and associated with your user profile.
That way, the next time you use the display, the widgets are where you previously placed them.
286 TMX-2050 Display User Guide Version 1.075, Revision C
