8 Implements Application control
Rate control
On the Settings screen for Rate Control:
1.
Tap next to Rate Control. This toggles rate control on or off for the current channel.
2.
After you turn on rate control, tap each setting and choose an option.
Tap... To...
Number of
Valves/Drives
The maximum number of drives is 1.
Control Valve/Drive
Type
Choose the type of drive that you is installed:
ll Fast Bypass Servo
l Fast Servo: 4-wire servo valve
l Hardi % Bypass
l PWM: 2-wire PWM valve (commonly used to control hydraulic
flow)
l Pump Servo
l Standard Bypass Servo
l Standard Servo: 2-wire standard servo valve
Note – Bypass (for Servo and Hardi drives only) means that the
controller is on the return-to-tank line. The valve closes to increase
the application rate.
Auxiliary Valve (for
inline
liquid/anhydrous
channels only)
Set the auxiliary valve:
ll Disable- The equipment does not have an auxiliary control valve.
l Dump - Valve opens to dump flow-to-return line when the
system is turned off.
l Master - Valve closes when the system is turned off.
Number of Nozzles
Enter the number of nozzles on the implement, between 1 and 999.
202 TMX-2050 Display User Guide Version 1.075, Revision C
