Trimble TMX-2050 - Modify a control channel; Remove a control channel

8 Implements Application control
1.
Review the channel details.
2. To change channel settings, tap Back until you reach the section you wish to edit..
3.
Tap . The display saves the channel and returns to the Application Control section for
implement setup.
4.
Tap Next to continue to:
a. Boom height control, 210, if applicable
b. Inputs, 219, if applicable
Modify a control channel
To edit an application control channel:
1.
Tap on the Home screen.The Implement setup panel displays.
2. Tap the implement you want to work with.
3. Tap APPLICATIONCONTROL.
4. Tap the control channel that you want to change, then tap Modify.
5.
Tap the button at the top of the screen for the channel setting that you want to change.
6. When you finish making changes, tap Summary at the top right corner of the screen.
7.
If any part of the setup is not complete, you can save the changes but you cannot use the
implement on the Run screen.
8.
To save the channel and return to the Application Control section , tap . The display returns
you to the Implement setup panel.
9.
To exit channel setup without saving, tap . The display returns you to the Implement
setup panel.
Remove a control channel
To remove an application control channel:
1.
Tap on the Home screen.The Implement setup panel displays.
2. Tap the implement you want to work with.
3. Tap APPLICATIONCONTROL.
4. Tap the control channel that you want to remove, then tap Remove. The system displays a
confirmation message for you to confirm that you want to remove the channel.
5.
Tap
208 TMX-2050 Display User Guide Version 1.075, Revision C
