Inputs 8 Implements
Inputs
At the INPUTSsection, you can add sensors available on your implement.
Add a sensor
1.
Turn Sensors on by tapping .
2.
Tap to add a sensor. The TYPE section displays.
Type of sensor
1. Choose the type of sensor you are using:
a. Air pressure
b. Liquid pressure
c. Vacuum pressure
2.
Turn the sensors feature on by tapping .
3.
Tap .
4. Tap the name entry box to edit the name of the sensor.
5. Tap Next to continue to the Location section.
Location of sensor
At this section, complete the following settings.
Tap... To...
Select Module
Select serial number of the sensor. The display reads the serial numbers
from the installed sensors.
Input Location on FIQ
Module
Select the port on the the Field-IQ system control module where the
sensor connects to the system.
Note – For bin level, RPM, and gate height sensors, this is set
automatically and cannot be changed.
Units
Select the measurement units used by the sensor.
Display in Control
Channel
Shows name of channel.Selected whether or not the sensor shows up in
the Sensors Area of the Rate Control Widget for the channel.
l No - if you do not want to see the sensor
l Channel number (1-6) - the material control channel where you want
to see the sensor
Version 1.075, Revision C TMX-2050 Display User Guide 219
