8 Implements Boom height control
e. Verify that the appropriate section of boom moved down.
f. Verify that the height readings for each sensor on that boom decreased.
g. Verify external switches are connected correctly by pressing each vehicle manual boom
control switch. The switch status corresponding to each input should turn green while the
switch is pressed.
7. If the booms operate as you expect, tap Next to continue to boom calibration. (See Boom
height calibration steps, 215.)
8. If the booms are not operating as you expect, you will not be able to calibrate and you will have
to troubleshoot the system.
218 TMX-2050 Display User Guide Version 1.075, Revision C
