Boom height control 8 Implements
Tap.... To....
Boom Control Layout
Select the option you want for controlling the boom height:
ll Control Booms +Center Section
l Control Booms +Monitor Center Section
l Control Booms Only
l Control Center Only
l Monitor Only:Shows the boom height on the Run screen,
without the option to automatically control boom height
Valve/Drive Module
S/N
Choose the serial number of the valve/drive module.
2. Tap Next to continue to Sensor location, 211.
For information on: See:
Control during
operation
Boom height control operation, 276
Adjustment
during operation
Boom height adjustments, 278
Sensor location
At the Sensor Location section of Boom Height settings:
1.
Tap Number of Height Sensors. Select the number of height sensors installed on the system.
2.
Tap each sensor box to complete the settings for the sensor.
Note – The current display shows the center section of the boom as a side view and the right
boom as the left boom. This does not hinder functionality or settings.
Tap... To....
Enabled Turn the sensor on or off.
Sensor S/N Select the serial number for the sensor. The display reads the
serial numbers from the installed sensors.
Side Offset
Enter the distance from the center line of the sensor to the hinge
point of the boom. (Does not apply to the center section.)
Nozzle Offset
Enter the distance from the transducer surface to the spray
nozzle tip.
3.
When finished, tap . The display returns to the SENSORLOCATION section.
Version 1.075, Revision C TMX-2050 Display User Guide 211
