8 Implements Boom height control
Tap... To...
Advanced
Opens the advanced settings:
Boom Down Rate: Reduce this setting to lower the maximum
downward speed of the boom.
Sensor Sensitivity: Low, normal or high.
Sensor Canopy Filter: Off or on
Sensor Ground Filter: Off, low, medium or high
Minimum Safety Height: Adjust this setting. When an individual
sensor measures a height less than this setting below the current
target height, the display will switch from using the average sensor
zone height to using just the lowest sensor's height (and ignore the
higher sensor). This setting only applies to multi-sensor zones.
l Lowering the threshold: Will make the system more aggressive
at raising a zone when a individual sensor is low, especially
when two sensors report different heights.
l Raising the threshold: will improve the boom roll stability.
Default is 4 inches (0.1m). Minimum = 0 (aggressive ground
avoidance. Maximum = 1.0 (effectively disabled).
Auto Disable Timeout: Sets the "Timeout" time frame if the system
"Enable" button was selected and the system was not "Engaged",
after this period of time the system will disable itself. 30 or 60
seconds.
Height Error Indicator Band: Adjust this setting. If the boom is
within this distance of the target height, the screen will indicate that
the system is at the target height.
Note – This setting is for on-screen indication and does not impact
performance. The system will still work to drive the boom closer to
the target height.
Roll Dampening Threshold: Use this height error threshold to help
dampen underdamped wins and improve roll stability. 4-8 inches
(0.1-0.2m) is typical. A value of 0 (default) disables this additional
dampening.
Tap Next to continue to Inputs, 219.
For information on: See:
Control during
operation
Boom height control operation, 276
214 TMX-2050 Display User Guide Version 1.075, Revision C
