Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-53
Theory of Operation
Development and Toner Collection
s6500-066
Main Drive Sub Drive
Imaging Unit Gear 1
Xerographics Housing (Y, M, C, K)
[ Drum ]
Imaging Unit Gear 2
Cleaning Auger Gear
Magnet Idler Gear
Paddle Idler Gear
Paddle Gear
Auger Gear
Auger Gear
Side Auger Idler Gear
Side Auger Gear
[ Side Cleaning Auger ] [ Developer Paddle ]
[ Auger Front ]
[ Auger Rear ]
[ Auger ]
Developer Housing (Y, M, C, K)
[ Magnet Roller ]
Magnet Gear (Y, M, C, K)
Imaging Unit
