Xerox Phaser 6500 Service Manual

8-4 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Service Parts Disassembly
Notations in the Disassembly Text
• The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
•The notation “PLX.X.X” indicates the component is listed in the Parts List.
• Arrows in an illustration show direction of movement when removing or
replacing a component.
• The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Replacement Note
Provides information specific to the replacement of parts or assemblies.
Imaging Unit
Toner Cartridges
Fuser Assembly
s6500-505
Paper Tray
Separator Roller
Feed Roller
ADF Feed Roller
Assembly
ADF Separator Pad
Assembly
