Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-65
Error Messages and Codes
Waiting for “Continue” key to be pressed after reloading paper to the SSF
Applicable Error Code
• 024-985
IPv6 duplicate / IPv4 duplicate
Applicable Error Codes
• 027-446 / 027-452
6 Replace the IP Board. (SFP,
page 8-120; MFP, page 8-144)
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP
PL8.1.7; MFP PL8.1.2)
■ “Map 3 - SFP IP Board, LVPS, and Drive” on
page 10-8
■ “Map 8 - MFP LVPS, IP Board, and Drive” on
page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the error.
Does the error still occur when the
power is turned Off and On?
Replace the IP
Board. (SFP,
page 8-120; MFP,
page 8-144)
Complete.
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the IP addresses and remove
any duplicate IP addresses.
Does the error still occur when the
power is turned Off and On?
Update the
firmware
(“Firmware
Update” on
page A-16).
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
