Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-105
Error Messages and Codes
IOT Feeder 2 JAM
Applicable Error Code
• 072-101
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Cassette Assy 250 (PL2.1.1)
■ Separator Holder Assy (PL2.1.5)
■ Left Side Harness Assy (PL3.1.18)
■ Drive Clutch and Regi Bearing Kit
(PL3.1.97)
■ Feeder Assy (PL3.1.98)
■ Feed Solenoid Kit (PL3.1.99)
■ Feed Roller Assy (PL3.2.4)
■ Registration Input Actuator
(PL3.2.11)
■ Registration Sensor (Sensor Photo)
(PL3.2.13)
■ Main Drive Assy (PL7.1.2)
■ Feed Drive Assembly (PL7.1.4)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
■ “Map 5 - SFP Optional Feeder” on
page 10-10
■ “Map 10 - MFP Optional Feeder” on
page 10-19
■ “SFP Option Feeder” on page 10-35
■ “MFP Option Feeder” on page 10-50
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the paper condition.
Is the paper in Tray 1 or Tray 2
wrinkled or damaged?
Replace with
new, dry paper,
then go to step
2.
Go to step 3.
2 Does the error still occur when
printing?
Go to step 3. Complete.
3 Load new paper in Tray 1 or Tray 2.
Does the error still occur when
printing?
Go to step 4. Complete.
4 Check the Front Cover for latching.
Open and close the Front Cover, and
then latch correctly.
Does the error still occur when
printing?
Go to step 5. Complete.
5 Perform the procedure “Main Drive
Assembly” on page 4-29.
Does the Main Motor (Main Drive
Assy) operate properly?
Go to step 6. Go to step 19.

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
