Xerox Phaser 6500 Service Manual

1-4 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Information
Parts of the Printer
SFP Front and Side Views
1. Optional 250-sheet Feeder (Tray 2)
2. Media tray (Tray 1 if optional 250-sheet feeder is installed).
3. Manual Feed slot
4. Front Cover
5. Control Panel
6. Output tray
7. Button for opening the Front Cover and releasing the Duplex Unit.
8. Toner Cartridges
9. Toner Door
s6500-001
5
6
4
3
2
1
8
9
7
