Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-37
Error Messages and Codes
ADF Cover Open
Applicable Error Code
• 005-301
4 Check the paper feeding
Does the ADF feed the document?
Go to step 5. Go to step 7.
5 Check the document path
Open the ADF Cover and check the
document path.
Is there a foreign substance on the
document path?
Remove the
foreign
substance.
Go to step 6.
6 Replace the ADF Assy. (page 8-192)
Does the error still occur when
copying?
Replace the IP
Board
(page 8-144).
Complete.
7 Check the ADF Feed Roller installation
Is the roller installed correctly?
Also are they not contaminated or
damaged, and rotate smoothly?
Replace the
ADF Assy.
(page 8-192).
Replace the
Feed Roller
Assy &
Separator Pad
Assy.
(page 8-13.)
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■ ADF Assy (PL10.1.3)
■ ADF Top Cover (PL10.1.4)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “ADF” on page 10-48
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Is the ADF Cover completely closed? Go to step 2. Close the
ADF Cover.
2 Is the ADF Cover damaged? Replace the
ADF Cover.
Go to step 3.
3 Reseat the connector (P/J1003) on the IP
Board.
Does the error still occur when copying?
Go to step 4. Complete.
4 Check after replacing the ADF ASSY
Replace the ADF Assy. (page 8-192)
Does the error still occur when copying?
Replace the
IP Board.
(page 8-144)
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
