Xerox Phaser 6500 Service Manual

10-44 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
MFP HVPS
MCU Board
PL8.2.13
P/J16
1
2
3
4
5
6
7
8
HVPS
PL4.1.19
HVPS Harness Assembly
PL9.1.5
P/J161
CF
DF-K
TR-K
TR-C
TR-M
TR-Y
BCR
BTR
BTR : Bias Transfer Roller
BCR : Bias Charge Roller
Developer
DB-C
DB-M
DB-Y
10
9
8
7
6
5
4
3
TR MON
NC
HV DO
HV LD
HV CLK
+3.0V REF
SG
9
10
2
1
MAIN CLK
SG
I/L +24V
s6500-462
K
C
M
Y
+3.0V REF
+24VDC
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
