Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-77
Error Messages and Codes
Buffer Over
Applicable Error Codes
• 033-774 / 033-776
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ FAX Board (MFP PL8.1.5)
■ MFP IP Board (ESS) (MFP PL8.1.2)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the resolution setting.
Retry sending by lowering the
resolution setting.
Does the error still occur when faxing?
Go to step 2. Complete.
2 Check the firmware version.
Is the firmware the latest version?
Go to step 3. Update the
firmware
(“Firmware
Update” on
page A-16),
then go to step
3.
3 Replace the FAX Board. (page 8-143)
Does the error still occur when faxing?
Replace the IP
Board.
(page 8-144)
Complete.
