General Information
Internal View, MFP
1. Front Cover and Duplex Unit release
2. Tr a n s fe r B e l t
3. I m a g i n g U n i t
4. Fu s e r
5. D o c u m e n t G l a s s
6. Toner Cartridges
7. D u p l e x U n i t
1
2
3
4
5
6
7
s6500-007
