Xerox Phaser 6500 Service Manual

10-38 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
MFP Wiring Diagram Descriptions
The connections illustrated on each of the wiring diagrams are listed below.
Wiring Diagram Description
LVP S Connections between LVPS and MCU Board.
Connections of AC Power Switch to LVPS.
Connections between Interlock Harn Assy with LVPS.
Connection of Toner Door Switch to MCU Board.
Media Feed Connections of Feed Solenoid with MCU Board.
Connections of Registration Sensor with MCU Board.
Connections of Manual Feed (SSF) No Paper Sensor with MCU Board.
Connections of Tray 2 No Paper Sensor with MCU Board.
Connections of Drive Clutch with MCU Board.
Main Drive Connections of Feeder Drive with MCU Board.
Connections of Main Drive with MCU Board.
Connections of Sub-Drive with MCU Board.
Laser Unit Connections of Laser Unit with MCU Board.
Xerographics Connections of EEPROM Board with MCU Board.
Connections of Imaging Unit (PHD) with MCU Board.
Connections of Hum/Temp Sensor with MCU Board.
Connections of Erase LEDs and MCU Board.
Connections of Transfer Belt with MCU Board.
HVPS Connections of HVPS with MCU Board.
Ton er Dispe nse Connections of Dispenser Motor (Y) with MCU Board.
Connections of Dispenser Motor (M) with MCU Board.
Connections of Dispenser Motor (C) with MCU Board.
Connections of Dispenser Motor (K) with MCU Board.
Connections of CRUM Connector (Y) with MCU Board.
Connections of CRUM Connector (M) with MCU Board.
Connections of CRUM Connector (C) with MCU Board.
Connections of CRUM Connector (K) with MCU Board.
Fuser Connections of Fuser with MCU Board.
Connections of Fuser with LVPS.
Connections of MCU Board with LVPS.
System Control Connections of Image Processor Board with MCU Board.
Connections of Control Panel with Image Processor Board.
Connections of LVPS with Image Processor Board.
ADF Connections of Image Processor Board with Scanner ADF Assy.
Scanner Connections of Image Processor Board with Scanner IIT Assy.
Connections of Image Processor Board with Front USB Assy
Option Feeder Connections of Optional Feeder Tray 2.
Duplex Unit Connections of Duplex Unit with MCU Board.
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
