Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-163
Error Messages and Codes
Fax Card Modem Error
Applicable Error Code
• 134-211
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2)
■ FAX Board (MFP PL8.1.5)
—
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Cycle the power Off, then On.
Does the error still occur when faxing?
Go to step 2. Complete.
2 Reseat the FAX Board. (page 8-143)
Does the error still occur when faxing?
Go to step 3. Complete.
3 Replace the FAX Board. (page 8-143)
Does the error still occur when faxing?
Replace the IP
Board. (MFP,
page 8-144)
Complete.

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
