Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-63
Error Messages and Codes
IOT Start Image Marking Time-out
Applicable Error Code
• 024-362
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (SFP PL8.1.7; MFP
PL8.1.2)
■ “Map 3 - SFP IP Board, LVPS, and Drive”
on page 10-8
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the firmware version
Is the firmware the latest version?
Go to step 2. Update the
firmware
(“Firmware
Update” on
page A-16),
then go to step
2.
2 Check the error.
Does the error still occur when
printing?
Replace the IP
Board. (SFP,
page 8-120;
MFP,
page 8-144)
Complete.

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
