3-58 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
PWBA FAX (FAX Board) Error
Applicable Error Codes
• 017-971 / 017-972 / 017-973 / 017-974
• 033-510 / 033-751 / 033-753 / 033-754 / 033-755 / 033-756 / 033-757 / 033-
758 / 033-759 / 033-760 / 033-761 / 033-763 / 033-764 / 033-765 / 033-766
/ 033-767 / 033-769 / 033-770 / 033-771 / 033-772 / 033-773 / 033-786 /
033-787
• 035-792
• 133-231 / 133-234 / 133-235 / 133-236 / 133-237 / 133-238 / 133-239 /
133-240 / 133-241 / 133-242 / 133-243 / 133-244 / 133-246 / 133-247 /
133-248 / 133-249 / 133-251 / 133-252 / 133-253 / 133-254 / 133-280
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2)
■ FAX Board (MFP PL8.1.5)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Is the firmware the latest version? Go to step 2. Update the
firmware
(“Firmware
Update” on
page A-16), then
go to step 2.
2 Is the phone line analog? Go to step 3. Make customer
aware that the
WC6505 supports
only analog fax
connections.
3 Connect an analog handset and
listen to the connection.
Is the line free of hum or severe
noise?
Go to step 4. Make sure line
polarity is not
reversed, and that
the line is properly
grounded.
Customer might
need to contact
phone provider.
4 Replace the FAX Board.
(page 8-143)
Does the error still occur when
faxing?
Replace the IP
Board.
(page 8-144)
Complete.
