Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 7-5
Cleaning and Maintenance
Moving the Printer
The Phaser 6500, with Tray 1 and consumables installed weighs 18.6 kg (41 lb.).
Configured with the Duplex Unit and Optional Feeder, the printer weighs 24.2 kg
(53.24 lb.).
The WorkCentre 6505, with Tray 1 and consumables installed weighs 28.8 kg (63.5
lb.). Configured with the Duplex Unit and Optional Feeder, the printer weighs 34.5
kg (76.0 lb.)
Warning
Remove the Optional Feeder before moving the printer. The Optional Feeder is
secured with 2 thumbscrews located in the Tray cavity. See “Optional Feeder”
on page 167.
To avoid injury, use two people to lift the printer.
s6500-171
18.6 kg
41 lb.

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
