Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-17
Wiring
Map 8 - MFP LVPS, IP Board, and Drive
A
132
133
134
135
136
137
138
139
140
141
142
143
144
145
131
BCDEFGHI J KL
s6500-433
40
503
44
502
48
47
504
501
1003
1002
2401*
1001
221
211
403
2501*
2002
2001
802
201
273
241
801
261
262
1301
2103*
: Not Connected

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
