2-22 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
Feeder
•Tray No Paper Sensor
Detects the presence/absence of paper in the Tray based on the position of
No Paper Actuator.
s6500-037
s6500-038
Tray No Paper Sensor
No Paper Actuator
(No Paper Position)
Tray No Paper Sensor
Paper
No Paper Actuator
Bottom Plate
