Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 1-5
General Information
MFP Front and Side views
1. Scanner & Automatic Document Feeder
2. Output tray
3. Button for opening the Front Cover and releasing the Duplex Unit.
4. Power switch
5. Toner Door
6. Manual Feed slot
7. Media tray (Tray 1 if optional 250-sheet feeder is installed).
8. Front Cover
9. Control Panel
10. USB Port (Type A)
s6505-003
10
9
8
6
7
1
2
3
4
5
