Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-47
Error Messages and Codes
LDAP Address Book - Access Error
Applicable Error Code
• 016-530
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2) ■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the LDAP settings
Is LDAP set correctly?
Go to step 4. Verify that
LDAP settings
are correct in
CWIS.
2 Check the firmware version
Is the firmware the latest version?
Go to step 3. Update the
firmware
(“Firmware
Update” on
page A-16),
then go to step
3.
3 Check the IP Board installation
Reseat the IP Board. (SFP, page 8-120;
MFP, page 8-144)
Does the error still occur when turning
the power Off and On?
Replace the IP
Board. (SFP,
page 8-120;
MFP,
page 8-144)
Complete.
To Next Page
